5-16
11. Strobe White Balance Adjustment
Adjust the white balance when the strobe light flashes.
Subject A plate which reflection rate is 18%
(1.0m from the front of the protection
glass)
Measurement Point Display data of page : 1
Measuring Instrument Adjustment remote commander
Adjustment Page E
Adjustment Address 42, 43
Note 1: Perform this adjustment in the dark room or use a dark box.
Note 2: Any light other than the strobe light should not light up the plate.
Note 3: Displayed data of page 1 of the adjustment remote commander.
1 :XX:XX
Strobe B data
Strobe R data
Switch setting:
1) Flash emitter .................................................................. Open
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 11, set data: 15, and press the PAUSE
button of the adjustment remote commander.
3) Select page: 2, address: 10, and set data: 58.
4) Select page: 2, address: 56, and set data: 89.
5) Select page: 2, address: 90, and set data: 00.
6) Select page: 2, address: 91, and set data: 00.
7) Select page: 2, address: 92, and set data: 00.
8) Select page: 2, address: 93, and set data: 80.
9) Select page: 2, address: 01, set data: 79, and press the PAUSE
button.
10) Select page: 2, address: 01, set data: 67, and press the PAUSE
button.
11) Check the flashing of the strobe light.
12) Select page: 0, address: 03, and set data: 05.
13) Select page: 1, and read the strobe R data and strobe B data.
14) Select page: E, address: 42, set the strobe R data, and press the
PAUSE button.
15) Select page: E, address: 43, set the strobe B data, and press the
PAUSE button.
Processing after Completing Adjustments
1) Select page: E, address: 11, set data: 18, and press the PAUSE
button of the adjustment remote commander.
2) Select page: 0, address: 01, and set data: 00.
3) Select page: 0, address: 03, and set data: 00.
4) Select page: 2, address: 01, set data: 00, and press the PAUSE
button of the adjustment remote commander.
5) Select page: 2, address: 10, and set data: 00.
6) Select page: 2, address: 56, and set data: 00.
7) Select page: 2, address: 90, and set data: 00.
8) Select page: 2, address: 91, and set data: 00.
9) Select page: 2, address: 92, and set data: 00.
10) Select page: 2, address: 93, and set data: 00.
12. Strobe Light Level and White Balance Check
Check the light level regulation and the white balance when the
strobe light flashes.
Subject A plate which reflection rate is 18%
(1.0m from the front of the protection
glass)
Measurement Point Display data of page : 1
Measuring Instrument Adjustment remote commander
Specified Value Y level data : 70 to 95 (Note 3)
R-Y data : FA to FF or 00 to 06 (Note 4)
B-Y data : FA to FF or 00 to 06 (Note 4)
Note 1: Perform this adjustment in the dark room or use a dark box.
Note 2: Any light other than the strobe light should not light up the plate.
Note 3: Display data of page 1 of the adjustment remote commander.
1 :00:XX
Y level data
Note 4: Display data of page 1 of the adjustment remote commander.
1 :XX:XX
B-Y data
R-Y data
Switch setting:
1) Flash emitter .................................................................. Open
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: E, address: 11, set data: 15, and press the PAUSE
button of the adjustment remote commander.
3) Select page: 2, address: 10, and set data: 58.
4) Select page: 2, address: 56, and set data: 89.
5) Select page: 2, address: 90, and set data: 00.
6) Select page: 2, address: 91, and set data: 00.
7) Select page: 2, address: 92, and set data: 00.
8) Select page: 2, address: 93, and set data: 80.
9) Select page: 2, address: 01, set data: 79, and press the PAUSE
button.
10) Select page: 2, address: 01, set data: 67, and press the PAUSE
button.
11) Check the flashing of the strobe light.
12) Select page: 0, address: 03, and set data: 01.
13) Select page: 1, and check that the Y level data satisfies the
specified value. (Note 3).
14) Select page: 0, address: 03, and set data: 04.
15) Select page: 1, and check that the R-Y data satisfies the specified
value and the B-Y data satisfies the specified value. (Note 4)
Processing after Completing Adjustments
1) Select page: E, address: 11, set data: 18, and press the PAUSE
button of the adjustment remote commander.
2) Select page: 0, address: 01, and set data: 00.
3) Select page: 0, address: 03, and set data: 00.
4) Select page: 2, address: 01, set data: 00, and press the PAUSE
button of the adjustment remote commander.
5) Select page: 2, address: 10, and set data: 00.
6) Select page: 2, address: 56, and set data: 00.
7) Select page: 2, address: 90, and set data: 00.
8) Select page: 2, address: 91, and set data: 00.
9) Select page: 2, address: 92, and set data: 00.
10) Select page: 2, address: 93, and set data: 00.
