6-2
not
supplied
not
supplied
not
supplied
58
56
52
51
54
53
61
62
55
60
59
57
LCD902
51 3-713-791-81 SCREW (M1.7)
52 X-3949-130-1 CABINET (ST) ASSY
53 3-968-729-51 SCREW (M2), LOCK ACE, P2
54 3-718-233-01 NUT, PLATE
55 3-965-034-01 SPRING, COMPRESSION
56 X-3949-134-1 CABINET ASSY, EVF
* 57 X-3948-659-1 HOLDER ASSY, LENS
* 58 3-960-302-11 CUSHION (1), LCD
59 A-7073-754-A VF-131 BOARD, COMPLETE
60 1-671-875-11 FP-68 (VF-FC) FLEXIBLE BOARD
61 A-7073-752-A MA-348 BOARD, COMPLETE
62 1-959-176-11 HARNESS (MA-151)
LCD902 8-753-023-51 LCX027AK-1
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
6-1-2. EVF SECTION
