5-3
Fig. 5-1-5.
Adjustment
remote commander
CPC-12
(J-6082-436-A)
LANC
jack
Oscilloscope
CH1
EXT.TRIG.
VG
COM
GND
8
4
9
Must be connected
when the electronic
viewfineder
is used.
Must be connected
when the FLASH UNIT
is used.
Must be connected
when the MIC UNIT is used.
PK-45
board
CN941
CN603
CN602
CN601
CN701
FDD UNIT
CN013
CN012
CN011
Extension cable
(J-6082-427-A)
Extension cable
(16P, 0.5mm)
(J-6082-357-A)
CD-207 board
Lens block
SW
BLOCK
ZM
BLOCK
CN702
CN704
CN401
CN001
CN101
CN701
CN601
CN603
FC-67
board
CN703
CN602
CN301
DD-119
board
CN303
RL-52 board
CN103
AC power adaptor
(BC-V615)
Extension cable (50P, 0.5mm)
(J-6082-434-A)
BATTERY
HOLDER
MF UNIT
CN401
Note 1: When connecting the extension cable,
refer to “1. Connection between the FDD
unit and PK-45 board” of page 6.
Note 2: In changing data, wait for more than 5 seconds
after the set was turned on, then change the data.
Note 3: Connect the GND terminal to Floppy disk drive unit
frame when check the RF signal waveform.
