18
z Tip
• Indicators may look different or appear at
different positions.
Data during recording
The date, time, and recording conditions are
recorded automatically.
They are not displayed while recording.
However, you can check them by selecting
(DISPLAY SET) t [DATA CODE]
and choosing the data that you want to
display, or by pressing the ASSIGN button
to which the DATA CODE function is
assigned, during playback.
ISO800 ISO sensitivity (p. 44)
9dB Gain (p. 44)
100 180° Shutter speed (p. 44)
AVCHD audio format
(p. 116)
-2.0EV AE shift (p. 104)
/
Auto setting/manual
setting (p. 43)
n A
B 6500K
White balance (p. 46)
Histogram (p. 118)
LOW LUX (p. 54)
Audio level display
(p. 120)
Digital extender (p. 104)
REC LEVEL MODE
(p. 116)
NIGHTSHOT (p. 54)
SELECTED MIC
(p. 117)
ND filter (p. 45)
Gamma display assist
(p. 57)
Indicator Meaning
Screen Indicators (Continued)

Sony NXCAM HXR-NX80 Specifications

General

Lens	ZEISS Vario-Sonnar T*
Optical Zoom	12x
ND Filter	Clear, 1/4, 1/16, 1/64
Image Stabilization	Optical SteadyShot with Active Mode
Maximum Resolution	3840 x 2160 (4K)
Microphone	Built-in stereo microphone
Memory Card Slots	Dual SD card slots
Effective Pixels	14.2MP
Digital Zoom	48x
Focal Length	9.3 - 111.6 mm
Aperture	f/2.8 - f/4.5
Minimum Focusing Distance	1 cm (Wide)
Recording Format	XAVC S, AVCHD
Frame Rate	Up to 120fps (HD)
Audio Recording	Linear PCM 2ch, Dolby Digital 2ch
LCD Screen	3.5-inch (1.56 million dots) touchscreen LCD
Viewfinder	0.39-inch type OLED, approx. 2.36 million dots
Battery	NP-FV70A
Dimensions	89.5 x
Connectivity	HDMI, USB, Wi-Fi, NFC
