Sony SA-CT800 - Loudspeaker (L-Ch) (SP1)

HT-CT800
15
2-9. LOUDSPEAKER (L-CH) (SP1)
270 mm
loudspeaker (L-ch)
5 two screws
(BVTP3.5)
6 loudspeaker
(L-ch) (SP1)
3 terminal (wide)
[gray]
3 terminal (narrow)
[black]
2 Draw the connection cable
out of the groove.
Note 1:
Lay a soft piece of cloth under the unit
to avoid damaging the top cabinet assy.
packing
(CL3)
5 screw
(BVTP3.5)
5 screw
(BVTP3.5)
top cabinet block
2
4
3
5
1
4 connection
cable block
(L-ch)
rear side
left side
1 tape
1 two
tapes
,QVWDOODWLRQSRVLWLRQRIWKHSDFNLQJ&/
&RQQHFWLRQFDEOH/FKVHWWLQJ
groove
packing (CL3)
packing (CL3)
[gray]
[black]
loudspeaker (L-ch)
(SP1)
left side
tape
two tapes
Press.
front side
Note 2:
Take care not to crush
the front grille.
loudspeaker (L-ch) (SP1)
wide
narrow
,QVWDOODWLRQGLUHFWLRQIRUWKH
ORXGVSHDNHU/FK63
rear side
left side
OK
NG
OK
NG
Note 3:
When connecting the terminals of the
connection cable to the loudspeaker, be
careful of the direction of the terminals.
,QVWDOODWLRQGLUHFWLRQZKHQFRQQHFWLQJWKH
WHUPLQDOVRIWKHFRQQHFWLRQFDEOH/FK
