Sony SA-CT800 - BTW (WIFI) Board

HT-CT800
19
2-14. BTW (WIFI) BOARD
6 ± 3 mm 6 ± 3 mm265 mm
6 ± 3 mm 6 ± 3 mm325 mm
,QVWDOODWLRQGLUHFWLRQIRUWKH%7::,),ERDUGDQGDQWHQQDKROGHU
front side
left side
right side
Triangle shape.
marking
marking
marking
Triangle shape.
Triangle shape.
Upward arrow.
Upward arrow.
3 coaxial harness
block [gray]
3 coaxial harness
block [white]
2 connector
[gray]
2 connector
[white]
coaxial harness
[gray]
coaxial harness
[white]
1 antenna holder
1 antenna holder
1 antenna holder
4 BTW (WIFI-2) board
4 BTW (WIFI-1) board
top side
left side
right side
3DVWLQJSRVLWLRQRIWKHFXVKLRQ7
coaxial harness [gray]
coaxial harness [white]
cushion (T03)
cushion (T03)
3DVWLQJSRVLWLRQRIWKHFXVKLRQ7
BTW (WIFI-1) board
BTW (WIFI-2) board
front side
rear side
rear side
SYSSET
