Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT800
65
A-2092-220-A NFC BOARD, COMPLETE
********************
When the NFC board is defective, replace the complete mounted board.
The mounted parts cannot be replaced with single for repairing.
*************************************************************
A-2083-659-A POWER BOARD, COMPLETE (US, CND, TW)
A-2143-840-A POWER BOARD, COMPLETE
(AEP, UK, SP1, AR, TH, LA, AUS, CH)
A-2143-842-A POWER BOARD, COMPLETE (E3, EA3)
**********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CONNECTOR >
0 * CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
0 D901 8-719-077-77 DIODE D3SB60F3 (See Note)
0 D930 6-503-021-01 DIODE DZ2J10000L
0 D931 8-719-083-71 DIODE UDZSUSTE-1730B
0 D932 6-502-975-01 DIODE DZ2J15000L
0 D934 6-502-961-01 DIODE DA2J10100L
0 D936 6-501-119-01 DIODE RR264M-400
0 D937 6-501-119-01 DIODE RR264M-400
0 D938 6-503-731-01 DIODE SARS10
0 D939 6-503-037-01 DIODE DZ2J24000L
0 D941 8-719-083-71 DIODE UDZSUSTE-1730B
0 D942 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D951 6-502-961-01 DIODE DA2J10100L
D952 6-503-038-01 DIODE DZ2J27000L
D966 6-501-849-01 DIODE FMX-22SL
D967 6-503-978-01 DIODE RB068L100TE25
D971 6-504-137-01 DIODE KDZVTR22B
0 D972 6-504-137-01 DIODE KDZVTR22B
D973 8-719-083-71 DIODE UDZSUSTE-1730B
0 D974 6-503-032-01 DIODE DZ2J180M0L (Except US, CND, TW)
0 D974 6-503-036-01 DIODE DZ2J220M0L (US, CND, TW)
0 D975 6-502-961-01 DIODE DA2J10100L
< FUSE >
0 F901 1-523-067-51 FUSE (5 A/250 V)
0 F931 1-523-085-11 FUSE (2.5 A/250 V) (See Note)
< IC >
0 IC930 6-720-460-01 IC STR-Y6735 (US, CND, TW)
0 IC930 6-721-976-01 IC STR-Y6766B (Except US, CND, TW)
IC931 6-716-865-01 IC MM1431FNRE
< LINE FILTER >
0 LF901 1-460-834-11 LINE FILTER (18MH MIN/1.5A) (US, CND, TW)
(See Note)
0 LF901 1-697-570-11 LINE FILTER TRANSFORMER (01C613
(Except US, CND, TW) (See Note)
< PHOTO COUPLER >
0 PH930 6-600-883-01 PHOTO COUPLER EL816S1 (B) (TA) (DTE-S)
< TRANSISTOR >
0 Q930 8-729-056-46 TRANSISTOR 2SC5053T100Q
0 Q931 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
Q951 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
< FUSIBLE RESISTOR >
0 R914 1-248-270-15 FUSIBLE 0.33 10% 1W F
(See Note)
< TRANSFORMER >
0 T901 1-697-487-11 CONVERTER TRANSFORMER
(Except US, CND, TW) (See Note)
0 T901 1-697-488-11 CONVERTER TRANSFORMER (US, CND, TW)
(See Note)
< THERMISTOR >
0 TH901 1-811-315-31 POWER THERMISTOR (See Note)
< VARISTOR >
0 VDR901 1-811-165-31 VARISTOR (TVR10471-D) (Except E3, EA3)
(See Note)
0 VDR901 1-812-256-31 VARISTOR (TVR10561-D) (E3, EA3) (See Note)
*************************************************************
SIRCS BOARD
***********
< CONNECTOR >
CN891 1-770-620-21 PIN, CONNECTOR 3P
< IC >
IC891 6-600-766-01 IC PNA4823M01S0
*************************************************************
TOUCH BOARD
************
< CONNECTOR >
CN1901 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
< FERRITE BEAD >
FB001 1-481-253-21 FERRITE, EMI (SMD) (1005)
< IC >
IC1901 6-722-496-01 IC CY8CMBR3108-LQXIT
IC1902 6-719-198-01 IC MM3411A33URE
*************************************************************
USB-CHUKEI BOARD
****************
< CONNECTOR >
CN1401 1-569-775-21 PIN, CONNECTOR (SMD) 5P
CN1402 1-822-423-11 CONNECTOR, USB (A) (
)
CN1451 1-770-623-21 PIN, CONNECTOR 6P
CN1453 1-820-899-21 CONNECTOR, FFC/FPC 6P
< DIODE >
D1401 6-500-400-01 DIODE BAV99-215
D1402 6-500-400-01 DIODE BAV99-215
NFC POWER SIRCS TOUCH USB-CHUKEI
Ver. 1.3
Note: When the D901, F931, LF901, R914, T901, TH901 or VDR901 on
the POWER board is replaced, refer to “BOND FIXED POSITION
OF ELECTRICAL PARTS” on page 8.
