Sony STR-DA3300ES - Page 110

110
STR-DA3300ES/DG1100
IC8009 NJU7313AM (TE2)
– DSP Board –
IC1 SI-3010KM-TL
2
L1
1
VEE
3
L2
4
L3
5
L4
6
L_COM1
7
L5
8
L6
9
L_COM2
10
L7
11
L8
12
L_COM3
13
NC
14
ST
15
GND
LEVEL SHIFTER
LATCH CIRCUIT
CONTROL
CIRCUIT
LATCH CIRCUIT
LEVEL SHIFTER
29
R1
30
VDD
28
R2
27
R3
26
R4
25
R_COM1
24
R5
23
R6
22
R_COM2
21
R7
20
R8
19
R_COM3
18
NC
17
DATA
16
CK
1VC
TSD
2VIN
3GND
4VOUT
5ADJ
+
–
REF
