Sony STR-DA3300ES - Electrical Parts List

15
STR-DA3300ES/DG1100
3. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1252-439-A MAIN BOARD, COMPLETE
(DA3300ES: AEP, ECE, UK)
A-1254-392-A MAIN BOARD, COMPLETE
(DA3300ES: US, CND)
A-1254-418-A MAIN BOARD, COMPLETE (DG1100)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1002 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1003 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1008 1-137-395-91 MYLAR 0.022uF 5% 100V
C1009 1-137-395-91 MYLAR 0.022uF 5% 100V
C1010 1-137-395-91 MYLAR 0.022uF 5% 100V
C1011 1-112-422-11 ELECT 470uF 20% 25V
(DA3300ES: AEP, ECE, UK)
C1011 1-126-941-11 ELECT 470uF 20% 25V
(DA3300ES: US, CND/DG1100)
C1012 1-112-077-11 ELECT 1000uF 20% 6.3V
(DA3300ES: AEP, ECE, UK)
C1012 1-126-916-11 ELECT 1000uF 20% 6.3V
(DA3300ES: US, CND/DG1100)
C1013 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1013 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1014 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1015 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1015 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1016 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1017 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1018 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1019 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1020 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1020 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1021 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1022 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1023 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1024 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1024 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1025 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1026 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1026 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1027 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1028 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1029 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1030 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
(DA3300ES: US, CND)
C1031 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1032 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1033 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1034 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1035 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1036 1-112-088-11 ELECT 10000uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1036 1-126-939-11 ELECT 10000uF 20% 16V
(DA300ES: US, CND/DG1100)
C1101 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1102 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1103 1-112-097-11 ELECT 2.2uF 20% 50V
(DA3300ES: AEP, ECE, UK)
C1103 1-126-961-11 ELECT 2.2uF 20% 50V
(DA3300ES: US, CND/DG1100)
C1104 1-112-084-11 ELECT 470uF 20% 16V
(DA3300ES: AEP, ECE, UK)
C1104 1-126-935-11 ELECT 470uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1106 1-125-896-91 MYLAR 0.0091uF 5% 50V
C1107 1-136-159-00 MYLAR 0.033uF 5% 50V
C1108 1-112-097-11 ELECT 2.2uF 20% 50V
(DA3300ES: AEP, ECE, UK)
C1108 1-126-961-11 ELECT 2.2uF 20% 50V
(DA3300ES: US, CND/DG1100)
C1109 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1110 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1111 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1112 1-112-114-11 ELECT 22uF 20% 50V
(DA3300ES: AEP, ECE, UK)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
CND : Canadian model
ECE : Russian and Ukrainian models
When indicating parts by reference number,
please include the board.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiquens pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
MAIN
