• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
Note 1: The process described in can be performed in any order.
Note 2: Without completing the process described in , the next process can not be performed.
SECTION 3
DISASSEMBLY
3-2. CASE
(Page 17)
3-4. CIS BOARD
(DA3300ES: US and Canadian
models/DG1100),
TUNER (FM/AM)
(Page 18)
3-6. TUNER BOARD,
CONTROL BOARD
(Page 19)
3-7. PREOUT BOARD (DA3300ES),
SUB WOOFER BOARD (DG1100)
AND S_SPTM BOARD
(Page 19)
3-11. AC BOARD,
POWER TRANSFORMER (T001)
(Page 22)
3-12. POWER AMP BLOCK
(Page 22)
3-3. FRONT PANEL BLOCK
(Page 17)
3-5. D_AUDIO BOARD,
DSP BOARD
(Page 18)
3-8. D_VIDEO BOARD
(Page 20)
3-9. A_VIDEO BOARD
(Page 20)
3-10. MAIN BOARD,
C_SPTM BOARD
(Page 21)
SET
Ver. 1.1
