3-10. MAIN BOARD, C_SPTM BOARD
3 CONNECTOR 4 board
6 CONNECTOR 3 board
8 connector
(CN1005)
1 connector
(CN1207)
4 connector
(CN1202)
5 connector
(CN1203)
2 connector
(CN1204)
qd C_SPTM board
qa five screws
(BVTP3
× 8)
qa two screws
(BVTP3
× 8)
qa screw
(BVTP3
× 8)
qs five screws
(BVTP3
× 8)
q; three screws
(BV/ring)
9 connector
(CN1020)
7 connector
(CN1401)
qf MAIN board
(DA3300ES: US and Canadian models)
