Sony STR-DA3300ES - 3 Electrical Parts List

17
STR-DA3300ES/DG1100
3. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1254-399-A A_VIDEO BOARD, COMPLETE
(DA3300ES: US, CND)
A-1254-410-A A_VIDEO BOARD, COMPLETE
(DA3300ES: AEP, ECE, UK)
A-1254-422-A A_VIDEO BOARD, COMPLETE (DG1100)
************************
< CAPACITOR >
C6001 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C6002 1-126-964-11 ELECT 10uF 20% 50V
C6003 1-126-964-11 ELECT 10uF 20% 50V
C6004 1-126-964-11 ELECT 10uF 20% 50V
C6005 1-126-964-11 ELECT 10uF 20% 50V
C6006 1-126-964-11 ELECT 10uF 20% 50V
C6007 1-126-964-11 ELECT 10uF 20% 50V
C6008 1-126-964-11 ELECT 10uF 20% 50V
C6009 1-126-964-11 ELECT 10uF 20% 50V
C6010 1-126-964-11 ELECT 10uF 20% 50V
C6011 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6014 1-126-947-11 ELECT 47uF 20% 35V
C6015 1-126-947-11 ELECT 47uF 20% 35V
C6101 1-126-962-11 ELECT 3.3uF 20% 50V
C6102 1-126-962-11 ELECT 3.3uF 20% 50V
C6103 1-104-658-91 ELECT 100uF 20% 10V
C6104 1-104-658-91 ELECT 100uF 20% 10V
C6105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6108 1-126-947-11 ELECT 47uF 20% 35V
C6109 1-126-916-11 ELECT 1000uF 20% 6.3V
C6110 1-126-947-11 ELECT 47uF 20% 35V
C6111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6115 1-126-947-11 ELECT 47uF 20% 35V
C6116 1-126-947-11 ELECT 47uF 20% 35V
C6117 1-126-947-11 ELECT 47uF 20% 35V
C6118 1-126-947-11 ELECT 47uF 20% 35V
C6233 1-126-947-11 ELECT 47uF 20% 35V
C6234 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6235 1-126-947-11 ELECT 47uF 20% 35V
C6243 1-126-947-11 ELECT 47uF 20% 35V
C6251 1-126-916-11 ELECT 1000uF 20% 6.3V
C6252 1-126-933-11 ELECT 100uF 20% 16V
C6253 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6254 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6301 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C6304 1-126-964-11 ELECT 10uF 20% 50V
C6305 1-126-964-11 ELECT 10uF 20% 50V
C6306 1-126-964-11 ELECT 10uF 20% 50V
C6307 1-126-964-11 ELECT 10uF 20% 50V
C6308 1-126-964-11 ELECT 10uF 20% 50V
(DA3300ES: US, CND)
C6309 1-126-964-11 ELECT 10uF 20% 50V
C6310 1-126-964-11 ELECT 10uF 20% 50V
(DA3300ES: US, CND)
C6311 1-126-964-11 ELECT 10uF 20% 50V
C6312 1-126-964-11 ELECT 10uF 20% 50V
(DA3300ES: US, CND)
C6313 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND)
C6314 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND)
C6315 1-126-964-11 ELECT 10uF 20% 50V
C6316 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C6317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND)
C6318 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6319 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6320 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6321 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND)
C6322 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND)
C6323 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C6324 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C6325 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C6326 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C6327 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C6328 1-126-947-11 ELECT 47uF 20% 35V
C6329 1-126-947-11 ELECT 47uF 20% 35V
C6501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6504 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C6505 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C6506 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND)
C6507 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
CND : Canadian model
ECE : Russian and Ukrainian models
When indicating parts by reference number,
please include the board.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiquens pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
A_VIDEO
Ver. 1.2
