18
STR-DA3300ES/DG1100
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C6508 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND)
C6509 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND)
C6510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6511 1-126-964-11 ELECT 10uF 20% 50V
(DA3300ES: US, CND)
C6512 1-126-964-11 ELECT 10uF 20% 50V
(DA3300ES: US, CND)
C6513 1-126-964-11 ELECT 10uF 20% 50V
C6514 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN6203 1-770-407-11 CONNECTOR, BOARD TO BOARD 12P
* CN6204 1-564-520-11 PLUG, CONNECTOR 5P
CN6501 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN6502 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D6001 6-501-817-01 DIODE MA2J1110GLS0
D6002 6-501-817-01 DIODE MA2J1110GLS0
D6003 6-501-817-01 DIODE MA2J1110GLS0
D6101 6-501-817-01 DIODE MA2J1110GLS0
D6102 6-501-817-01 DIODE MA2J1110GLS0
D6301 6-501-817-01 DIODE MA2J1110GLS0
D6302 6-501-817-01 DIODE MA2J1110GLS0
D6303 6-501-817-01 DIODE MA2J1110GLS0 (DA3300ES)
D6304 6-501-817-01 DIODE MA2J1110GLS0 (DA3300ES)
D6501 6-501-817-01 DIODE MA2J1110GLS0
D6502 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC6001 6-706-767-01 IC NJM2586AM
IC6101 8-759-822-05 IC LA7213
IC6102 8-759-822-05 IC LA7213
IC6103 6-701-820-01 IC LA73053-TLM-E
IC6104 6-706-767-01 IC NJM2586AM
IC6204 8-759-353-02 IC NJM2533M (TE2)
IC6205 8-759-647-11 IC uPC2905HF
IC6206 8-759-245-79 IC TA79005S
IC6301 6-704-199-01 IC NJM2595M-TE2 (DA3300ES)
IC6302 6-704-199-01 IC NJM2595M-TE2
IC6501 8-759-238-47 IC TC74HCT7007AF (EL)
IC6502 8-759-268-29 IC SN74HC595ANS
IC6503 8-759-268-29 IC SN74HC595ANS
IC6504 8-759-353-02 IC NJM2533M (TE2) (DA3300ES)
IC6505 8-759-353-02 IC NJM2533M (TE2)
< JACK >
J6001 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO
ASSIGNABLE (INPUT ONLY) VIDEO 1/
DVD/BD/SAT/CATV IN)
J6002 1-821-278-12 JACK 3P (COMPONENT VIDEO MONITOR OUT)
J6003 1-774-227-41 JACK, PIN 1P (ZONE 2 VIDEO OUT)
(DA3300ES: US, CND)
J6004 1-794-978-11 JACK, PIN 3P (VIDEO 1/VIDEO 2 VIDEO IN,
VIDEO 1 VIDEO OUT)
J6005 1-794-978-11 JACK, PIN 3P (DVD/BD/SAT/CATV VIDEO IN,
MONITOR VIDEO OUT)
< COIL >
L6001 1-469-525-91 INDUCTOR 10uH
L6002 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q6001 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6101 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q6102 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q6103 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6104 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R6001 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6002 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6003 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6004 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6005 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6006 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6007 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6008 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6009 1-211-990-11 METAL CHIP 75 0.5% 1/10W
0R6010 1-249-393-11 CARBON 10 5% 1/4W F
R6011 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6012 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6013 1-216-864-11 SHORT CHIP 0
R6014 1-216-864-11 SHORT CHIP 0
R6015 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6016 1-216-864-11 SHORT CHIP 0
R6017 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6018 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6101 1-216-815-11 METAL CHIP 330 5% 1/10W
R6102 1-216-815-11 METAL CHIP 330 5% 1/10W
R6103 1-216-847-11 METAL CHIP 150K 5% 1/10W
R6104 1-216-847-11 METAL CHIP 150K 5% 1/10W
R6105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6112 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6113 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6114 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6115 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6116 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6118 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6119 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6120 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6121 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6122 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6123 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6124 1-216-815-11 METAL CHIP 330 5% 1/10W
R6125 1-216-815-11 METAL CHIP 330 5% 1/10W
R6235 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6236 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6237 1-218-834-11 METAL CHIP 300 0.5% 1/10W
R6239 1-216-864-11 SHORT CHIP 0
R6240 1-216-864-11 SHORT CHIP 0
A_VIDEO
