STR-DA3300ES/DG1100
• IC Pin Function Description
TUNER BOARD IC8003 F2602E-01-TR (XM RECEIVER)
Pin No.
Pin Name I/O Description
1
LSOPTXRX - Not used
2
VSS - Ground terminal
3
SCTXOUT O Serial data output to the system controller
4
VDD - Power supply terminal (+3.3V)
5
SCRXIN I Serial data input from the system controller
6
VSS - Ground terminal
7
COMMSEL I Command mode selection signal input terminal Not used
8
VDD - Power supply terminal (+3.3V)
9
IRQ O Interrupt request signal output terminal Not used
10
VSS - Ground terminal
11
RESET I Reset signal input from the system controller "L": reset
12
SLAVESL I
Master/slave mode setting terminal "L": master mode, "H": slave mode
Fixed at "L" in this set
13
COMRXDIG - Not used
14
COMTXDIG - Not used
15
COMTXEN - Not used
16
VSS - Ground terminal
17
VDD - Power supply terminal (+3.3V)
18
COMRXP I XM receiver differential signal (positive) input terminal
19
COMRXM I XM receiver differential signal (negative) input terminal
20
VDD - Power supply terminal (+3.3V)
21
VSS - Ground terminal
22
COMTXM O XM transmitter differential signal (negative) output terminal
23
COMTXP O XM transmitter differential signal (positive) output terminal
24, 25
VSS - Ground terminal
26
OSCOUT O System clock output terminal (45.1584 MHz)
27
VDD - Power supply terminal (+3.3V)
28
OSCIN I System clock input terminal (45.1584 MHz)
29
VSS - Ground terminal
30
TEST - Not used
31
VSS - Ground terminal
32
HSDPDATA - Not used
33
VDD - Power supply terminal (+3.3V)
34
HSDPCLK - Not used
35
VSS - Ground terminal
36
HSDPEN - Not used
37
I2SDATA O I2S digital audio data output to the D/A converter and DSP
38
VSS - Ground terminal
39
I2SSCLK O I2S bit clock signal output to the D/A converter and DSP
40
VDD - Power supply terminal (+3.3V)
41
I2SLRCLK O I2S L/R sampling clock signal output to the D/A converter and DSP
42
VSS - Ground terminal
43
I2SOCLK O I2S over sample clock signal output to the D/A converter and DSP
44
VSS - Ground terminal
45
SAIICLK - Not used
46
VDD - Power supply terminal (+3.3V)
