Sony STR-DA3300ES - Page 136

136
STR-DA3300ES/DG1100
Pin No.
Pin Name I/O Description
AE15 to
AE20
OCMADDR20,
OCMADDR16,
OCMADDR13,
OCMADDR9,
OCMADDR6,
OCMADDR2
OAddress signal output to the flash memory
AE21 to
AE26
OCMDATA15,
OCMDATA11,
OCMDATA8,
OCMDATA2 to
OCMDATA0
I/O Two-way data bus with the flash memory
AF1
A2P - Not used
AF2
C2P - Not used
AF3
BN - Not used
AF4
A3P I Video signal input (CVBS) from VIDEO IN jack
AF5
C3P - Not used
AF6
CN - Not used
AF7
AN2 - Not used
AF8
CN2 - Not used
AF9
SVN - Not used
AF10,
AF11
LBADC_IN1,
LBADC_IN5
-Not used
AF12
AIP_RAW_HS_CS
-Not used
AF13
EXTOSD_CLK - Not used
AF14
AVSIN_SCL - Not used
AF15 to
AF20
OCMADDR21,
OCMADDR17,
OCMADDR14,
OCMADDR10,
OCMADDR7,
OCMADDR3
OAddress signal output to the flash memory
AF21 OCMADDR0 O Address signal output terminal Not used
AE22 to
AE26
OCMDATA12,
OCMDATA9
OCMDATA5 to
OCMDATA3
I/O Two-way data bus with the flash memory
