Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
171
STR-DA3300ES/DG1100
C3808 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C3809 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3810 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C3811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3812 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3813 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3814 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C3815 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3816 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3817 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3850 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C3851 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C3854 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C3855 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3856 1-127-956-21 FILM CHIP 0.1uF 5% 16V
C3857 1-127-956-21 FILM CHIP 0.1uF 5% 16V
C3858 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3859 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V
C3860 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C3861 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C3862 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3864 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3865 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3866 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C3867 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3868 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3869 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3870 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3873 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3874 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3875 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3876 1-126-207-11 ELECT CHIP 33uF 20% 4V
C3958 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3959 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3960 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C3961 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C3962 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C9364 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN3501 1-818-086-61 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) IN 1)
CN3502 1-818-086-61 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) IN 2)
CN3503 1-818-086-61 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) IN 3)
CN3504 1-818-086-61 HDMI CONNECTOR (HDMI OUT)
CN3505 1-770-406-11 CONNECTOR, BOARD TO BOARD 10P
CN3506 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P
CN3508 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
CN3602 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN3603 1-785-125-21 CONNECTOR 6P
* CN3605 1-764-250-11 PIN, CONNECTOR (PC BOARD) 4P
CN3801 1-770-407-11 CONNECTOR, BOARD TO BOARD 12P
< DIODE >
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
D3511 8-719-053-18 DIODE 1SR154-400TE-25
D3606 8-719-312-08 DIODE FMB-G16L
D3607 8-719-312-08 DIODE FMB-G16L
D3617 8-719-053-18 DIODE 1SR154-400TE-25
D3618 8-719-210-39 DIODE EC10QS-04
D3805 8-719-988-61 DIODE 1SS355TE-17
D3808 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
ET3501 1-780-318-11 TERMINAL
ET3502 1-780-318-11 TERMINAL
ET3503 1-780-318-11 TERMINAL
< FERRITE BEAD >
F3501 1-469-139-21 FERRITE, EMI (SMD) (2012)
F3502 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3501 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3502 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3503 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3504 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3505 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3506 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3601 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3602 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3603 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3604 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3605 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3606 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3607 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3608 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3609 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3610 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3611 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3612 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3613 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3614 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3615 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3616 1-469-152-11 FERRITE, EMI (SMD) (2012)
< COIL >
* FL3501 1-813-880-11 COMMON MODE CHOKE COIL
* FL3502 1-813-880-11 COMMON MODE CHOKE COIL
* FL3503 1-813-880-11 COMMON MODE CHOKE COIL
* FL3504 1-813-880-11 COMMON MODE CHOKE COIL
< IC >
IC3501 6-707-842-01 IC TC74LCX08FT (EKJ)
IC3503 6-710-819-01 IC TMDS341APFCR
IC3504 8-759-596-39 IC SN74LV4052APWR
IC3506 6-708-758-01 IC PCA9517DP.118
IC3508 8-759-596-39 IC SN74LV4052APWR
IC3509 6-704-001-01 IC BR24L02F-WSE2
IC3511 (Not supplied) IC SII9011CLU
IC3513 (Not supplied) IC SII9030CTU-7
IC3514 8-759-832-05 IC BA18BC0FP-E2
D_VIDEO
Note: IC3511 and IC3513 cannot exchange with single. When
IC3511 and IC3513 are damaged, exchange the entire
mounted bord.
