Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
177
STR-DA3300ES/DG1100
< CONNECTOR >
CN701 1-784-928-11 PIN, CONNECTOR 13P
CN702 1-784-926-11 PIN, CONNECTOR 11P
* CN706 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN710 1-784-930-11 PIN, CONNECTOR 15P
< DIODE >
D701 8-719-056-11 LED SML72423C-TP15 (ON/STANDBY)
D702 8-719-075-59 LED SELS5B23C-TP15 (Digital Cinema Sound)
D703 6-501-539-01 LED SELK5E20C-DTP15
(MULTI CHANNEL DECODING)
D704 8-719-041-97 DIODE MA113- (TX)
D705 8-719-041-97 DIODE MA113- (TX)
D706 8-719-041-97 DIODE MA113- (TX)
D707 8-719-041-97 DIODE MA113- (TX)
D708 6-501-743-01 DIODE MAZ8068GMLS0
D710 8-719-404-50 DIODE MA111-TX
< FERRITE BEAD >
FB701 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB702 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC701 6-600-349-31 IC NJL24H400A
IC702 6-705-468-01 IC BA33BC0FP-E2
IC703 8-759-825-56 IC NJM2173AV (TE2)
< JUMPER RESISTOR >
JW753 1-216-296-11 SHORT CHIP 0
< COIL >
L701 1-421-967-11 INDUCTOR 100uH
< FLUORESCENT INDICATOR TUBE >
ND701 1-519-954-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q701 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q702 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q703 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q704 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q705 8-729-808-42 TRANSISTOR 2SD1624-T
Q706 8-729-808-42 TRANSISTOR 2SD1624-T
Q708 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q709 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q710 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q711 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R701 1-216-037-00 RES-CHIP 330 5% 1/10W
R703 1-216-295-91 SHORT CHIP 0
R704 1-216-295-91 SHORT CHIP 0
(DA3300ES: AEP, ECE, UK/DG1100)
R705 1-216-295-91 SHORT CHIP 0 (DA3300ES: US, CND)
R706 1-216-001-00 RES-CHIP 10 5% 1/10W
0R707 1-249-385-11 CARBON 2.2 5% 1/4W F
0R708 1-249-385-11 CARBON 2.2 5% 1/4W F
R709 1-216-025-11 RES-CHIP 100 5% 1/10W
R710 1-216-025-11 RES-CHIP 100 5% 1/10W
R711 1-216-025-11 RES-CHIP 100 5% 1/10W
R712 1-216-025-11 RES-CHIP 100 5% 1/10W
R713 1-216-025-11 RES-CHIP 100 5% 1/10W
R714 1-216-025-11 RES-CHIP 100 5% 1/10W
R715 1-216-025-11 RES-CHIP 100 5% 1/10W
R716 1-216-025-11 RES-CHIP 100 5% 1/10W
R717 1-216-025-11 RES-CHIP 100 5% 1/10W
R718 1-216-025-11 RES-CHIP 100 5% 1/10W
R719 1-216-037-00 RES-CHIP 330 5% 1/10W
R720 1-216-025-11 RES-CHIP 100 5% 1/10W
R721 1-216-029-00 RES-CHIP 150 5% 1/10W
R723 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R724 1-216-049-11 RES-CHIP 1K 5% 1/10W
R725 1-216-081-00 RES-CHIP 22K 5% 1/10W
R726 1-216-073-91 RES-CHIP 10K 5% 1/10W
R727 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R728 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R729 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R730 1-216-049-11 RES-CHIP 1K 5% 1/10W
R731 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R733 1-216-049-11 RES-CHIP 1K 5% 1/10W
R734 1-216-083-00 RES-CHIP 27K 5% 1/10W
R735 1-216-049-11 RES-CHIP 1K 5% 1/10W
R736 1-216-049-11 RES-CHIP 1K 5% 1/10W
R737 1-216-833-11 METAL CHIP 10K 5% 1/10W
R740 1-216-833-11 METAL CHIP 10K 5% 1/10W
R741 1-216-833-11 METAL CHIP 10K 5% 1/10W
R748 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R749 1-216-821-11 METAL CHIP 1K 5% 1/10W
R750 1-216-849-11 METAL CHIP 220K 5% 1/10W
R751 1-216-843-11 METAL CHIP 68K 5% 1/10W
R753 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R754 1-216-821-11 METAL CHIP 1K 5% 1/10W
R757 1-216-025-11 RES-CHIP 100 5% 1/10W
R758 1-216-041-00 RES-CHIP 470 5% 1/10W
R759 1-216-073-91 RES-CHIP 10K 5% 1/10W
R772 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
< SWITCH/ROTARY ENCODER >
S701 1-771-349-21 SWITCH, KEYBOARD (MUSIC)
S702 1-771-349-21 SWITCH, KEYBOARD (MOVIE)
S703 1-771-349-21 SWITCH, KEYBOARD (A.F.D.)
S704 1-771-349-21 SWITCH, KEYBOARD (2CH/A.DIRECT)
S705 1-771-349-21 SWITCH, KEYBOARD (SUR BACK DECODING)
S706 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S707 1-771-349-21 SWITCH, KEYBOARD (DIMMER)
S708 1-771-349-21 SWITCH, KEYBOARD (MEMORY/ENTER)
S709 1-771-349-21 SWITCH, KEYBOARD (TUNING MODE)
S710 1-771-349-21 SWITCH, KEYBOARD (TONE MODE)
S711 1-771-349-21 SWITCH, KEYBOARD (ZONE SELECT)
(DA3300ES: US, CND)
S711 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
(DA3300ES: AEP, ECE, UK/DG1100)
S712 1-771-349-21 SWITCH, KEYBOARD (ZONE POWER)
(DA3300ES: US, CND)
DISPLAY
Ver. 1.2
