STR-DA3300ES/DG1100
AM tuner section
Tuning range
With 10-kHz tuning scale
530 – 1,710 kHz
3)
With 9-kHz tuning scale
531 – 1,710 kHz
3)
Antenna (aerial) Loop antenna (aerial)
3)
You can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down
TUNING MODE, press POWER on the receiver.
All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9
kHz), repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
/C
B
: 0.7 Vp-p, 75 ohms
P
R
/C
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
640 × 480p@60 Hz
720 × 480p@59.94/60 Hz
1440 × 480p@59.94/60 Hz (pixel sent 2times)
1280 × 720p@59.94/60 Hz
1920 × 1080i@59.94/60 Hz
1920 × 1080p@59.94/60 Hz
720 × 576p@50 Hz
1440 × 576p@50 Hz (pixel sent 2times)
1280 × 720p@50 Hz
1920 × 1080i@50 Hz
1920 × 1080p@50 Hz
1920 × 1080p@24 Hz
Genera l
Po
DA3300ES: US and Canadian models/DG1100:
wer requirements
Power output (DIGITAL MEDIA PORT)
DC OUT
120 V AC, 60 Hz
DA3300ES: AEP, Russian, Ukrainian and
UK models:
230 V AC, 50/60 Hz
(in countries/area in
Europe other than the U.K.)
230 – 240 V AC, 50/60 Hz
(in the U.K. and general area)
DA3300ES: US and Canadian models/DG1100:
350 W/480 VA (US/Canada)
DA3300ES: AEP, Russian, Ukrainian and
UK models:
390 W
: 5 V, 700 mA
Power consumption
Power consumption (during standby mode)
0.7 W (when “HDMI
Control” and “RS-232C
Control” are set to “OFF”)
Dimensions
430 × 175 × 430 mm
(width/height/depth)
including projecting parts
and controls
Mass (Approx.) 14.5 kg
Supplied accessories
Operating Instructions
Quick Setup Guide (1)
HDMI CONTROL Guide (1)
GUI Menu List (1)
Optimizer microphone ECM-AC2 (1)
FM wire antenna (aerial) (1)
AM loop antenna (aerial) (1)
AC power cord (mains lead) (1) (DA3300ES)
Remote commander RM-AAL011 (1)
(DA3300ES: US and Canadian models)
Remote commander RM-AAP019 (1)
(DA3300ES: AEP, Russian, Ukrainian and UK models)
(DA3300ES)
Remote commander RM-AAU018 (1)
(DG1100)
Remote commander RM-AAP018 (1)
R6 (size-AA) batteries
(4 (DA3300ES) or 2 (DG1100))
Design and specifications are subject to
change without notice.
Inputs (Analog)
Inputs (Digital)
Outputs
PHONO Sensitivity: 2.5 mV
Impedance: 50 kohms
S/N: 90 dB (A, 20 kHz
LPF)
MULTI CHANNEL
INPUT, SA-CD/CD,
MD/TAPE, DVD/BD,
TV, SAT/CATV,
VIDEO 1/2/3
Sensitivity: 150 mV
Impedance: 50 kohms
S/N: 100 dB (A, 20 kHz
LPF)
DVD/BD,VIDEO 2,
SA-CD/CD (Coaxial)
Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz
LPF)
VIDEO 1, VIDEO 3,
SAT/CATV, TV,
MD/TAPE (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
MD/TAPE (REC OUT),
VIDEO 1 (AUDIO OUT)
Vo ltage:150 mV
Impedance: 1 kohm
FRONT L/R, CENTER,
SURROUND L/R,
SUR BACK L/R, SUB
WOOFER
Vo ltage: 2 V
Impedance: 1 kohm
EQUALIZER
Gain levels ±10 dB, 1 dB step
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
Reference Power Output
(8 ohms 1 kHz, THD 10%)
FRONT
2)
:
130 W + 130 W
CENTER
2)
:
130 W
SURROUND
2)
:
130 W + 130 W
SURROUND BACK
2)
:
130 W + 130 W
Reference Power Output
(4 ohms 1 kHz, THD 10%)
FRONT
2)
:
130 W + 130 W
CENTER
2)
:
130 W
SURROUND
2)
:
130 W + 130 W
SURROUND BACK
2)
:
130 W + 130 W
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Power requirements: 230 V AC, 50/60 Hz
(in countries/area in Europe
other than the U.K.)
240 V AC, 50/60 Hz
(in the U.K. and general
area)
Frequency response
PHONO RIAA equalization curve
± 0.5 dB
MULTI CHANNEL
INPUT, SA-CD/CD,
MD/TAPE, DVD/BD,
TV, SAT/CATV,
VIDEO 1/2/3
10 Hz – 100 kHz
± 3 dB
Tu
DA3300ES: AEP, Russian, Ukrainian and
UK models:
DA3300ES: US and Canadian models/DG1100:
ning range 531 – 1,602 kHz
(With 9-kHz tuning scale)
Antenna (aerial) Loop antenna (aerial)
Ver. 1.2
