20
STR-DA3300ES/DG1100
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< TRANSFORMER >
0T002 1-445-212-11 TRANSFORMER, POWER
(DA3300ES: US, CND/DG1100)
0T002 1-445-213-11 TRANSFORMER, POWER
(DA3300ES: AEP, ECE, UK)
< THERMISTOR >
0TH50 1-804-046-11 THERMISTOR, POSITIVE (RXE030)
(DA3300ES: AEP, ECE, UK)
************************************************************
A-1252-439-A MAIN BOARD, COMPLETE
(DA3300ES: AEP, UK)
A-1254-392-A MAIN BOARD, COMPLETE
(DA3300ES: US, CND)
A-1254-418-A MAIN BOARD, COMPLETE (DG1100)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1002 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1003 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1008 1-137-395-91 MYLAR 0.022uF 5% 100V
C1009 1-137-395-91 MYLAR 0.022uF 5% 100V
C1010 1-137-395-91 MYLAR 0.022uF 5% 100V
C1011 1-112-422-11 ELECT 470uF 20% 25V
(DA3300ES: AEP, UK)
C1011 1-126-941-11 ELECT 470uF 20% 25V
(DA3300ES: US, CND/DG1100)
C1012 1-112-077-11 ELECT 1000uF 20% 6.3V
(DA3300ES: AEP, UK)
C1012 1-126-916-11 ELECT 1000uF 20% 6.3V
(DA3300ES: US, CND/DG1100)
C1013 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, UK)
C1013 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1014 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1015 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, UK)
C1015 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1016 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1017 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1018 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1019 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1020 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, UK)
C1020 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1021 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, UK)
C1022 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1023 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1024 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, UK)
C1024 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1025 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1026 1-112-083-11 ELECT 100uF 20% 16V
(DA3300ES: AEP, UK)
C1026 1-126-933-11 ELECT 100uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1027 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1028 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1029 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1030 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
(DA3300ES: US, CND)
C1031 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1032 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1033 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1034 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1035 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1036 1-112-088-11 ELECT 10000uF 20% 16V
(DA300ES: AEP, UK)
C1036 1-126-939-11 ELECT 10000uF 20% 16V
(DA300ES: US, CND/DG1100)
C1101 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1102 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1103 1-112-097-11 ELECT 2.2uF 20% 50V
(DA3300ES: AEP, UK)
C1103 1-126-961-11 ELECT 2.2uF 20% 50V
(DA3300ES: US, CND/DG1100)
C1104 1-112-084-11 ELECT 470uF 20% 16V
(DA3300ES: AEP, UK)
C1104 1-126-935-11 ELECT 470uF 20% 16V
(DA3300ES: US, CND/DG1100)
C1105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1106 1-125-896-91 MYLAR 0.0091uF 5% 50V
C1107 1-136-159-00 MYLAR 0.033uF 5% 50V
C1108 1-112-097-11 ELECT 2.2uF 20% 50V
(DA3300ES: AEP, UK)
C1108 1-126-961-11 ELECT 2.2uF 20% 50V
(DA3300ES: US, CND/DG1100)
C1109 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1110 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1111 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1112 1-112-114-11 ELECT 22uF 20% 50V
(DA3300ES: AEP, UK)
C1112 1-126-965-91 ELECT 22uF 20% 50V
(DA3300ES: US, CND/DG1100)
C1113 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1114 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1115 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1116 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1117 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1118 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1119 1-112-114-11 ELECT 22uF 20% 50V
(DA3300ES: AEP, UK)
C1119 1-126-965-91 ELECT 22uF 20% 50V
(DA3300ES: US, CND/DG1100)
C1120 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C1121 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DA3300ES: US, CND)
C1122 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1123 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1124 1-126-965-91 ELECT 22uF 20% 50V
(DA3300ES: US, CND)
MAINAC
Ver. 1.2
