22
STR-DA3300ES/DG1100
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TUNER
< RESISTOR >
R8001 1-216-864-11 SHORT CHIP 0
R8009 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8010 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8014 1-216-864-11 SHORT CHIP 0
(DA3300ES: US, CND/DG1100)
R8015 1-216-864-11 SHORT CHIP 0
(DA3300ES: US, CND/DG1100)
R8019 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8020 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8021 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8022 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8023 1-219-365-11 SHORT CHIP 0
(DA3300ES: US, CND/DG1100)
R8024 1-219-365-11 SHORT CHIP 0
(DA3300ES: US, CND/DG1100)
R8025 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8027 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8028 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8029 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8032 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8034 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8035 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8036 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8037 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8038 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8039 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8040 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8041 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8042 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: AEP, ECE, UK)
R8044 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: AEP, ECE, UK)
R8046 1-216-809-11 METAL CHIP 100 5% 1/10W
R8048 1-216-809-11 METAL CHIP 100 5% 1/10W
R8050 1-216-809-11 METAL CHIP 100 5% 1/10W
R8052 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8053 1-216-809-11 METAL CHIP 100 5% 1/10W
R8055 1-216-809-11 METAL CHIP 100 5% 1/10W
R8057 1-216-809-11 METAL CHIP 100 5% 1/10W
R8063 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8064 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8068 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8070 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8071 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8072 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(DA3300ES: US, CND/DG1100)
R8073 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(DA3300ES: US, CND/DG1100)
R8074 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8075 1-216-864-11 SHORT CHIP 0
(DA3300ES: US, CND/DG1100)
R8076 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8077 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8078 1-216-845-11 METAL CHIP 100K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8079 1-216-845-11 METAL CHIP 100K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8080 1-216-834-11 METAL CHIP 12K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8081 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8082 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8083 1-216-834-11 METAL CHIP 12K 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8084 1-216-819-11 METAL CHIP 680 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8085 1-216-819-11 METAL CHIP 680 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8086 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8087 1-216-809-11 METAL CHIP 100 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8088 1-216-805-11 METAL CHIP 47 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8089 1-216-805-11 METAL CHIP 47 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8090 1-216-805-11 METAL CHIP 47 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8091 1-216-819-11 METAL CHIP 680 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8092 1-216-805-11 METAL CHIP 47 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8093 1-216-805-11 METAL CHIP 47 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8094 1-216-805-11 METAL CHIP 47 5% 1/10W
(DA3300ES: US, CND/DG1100)
R8095 1-216-805-11 METAL CHIP 47 5% 1/10W
R8096 1-216-864-11 SHORT CHIP 0 (DA3300ES: AEP, ECE, UK)
< COMPOSITION CIRCUIT BLOCK >
RB8001 1-234-378-21 RES, NETWORK 10K (1005X4)
(DA3300ES: US, CND/DG1100)
RB8002 1-234-378-21 RES, NETWORK 10K (1005X4)
(DA3300ES: US, CND/DG1100)
RB8003 1-234-378-21 RES, NETWORK 10K (1005X4)
(DA3300ES: US, CND/DG1100)
RB8004 1-234-378-21 RES, NETWORK 10K (1005X4)
(DA3300ES: US, CND/DG1100)
RB8005 1-234-372-11 RES, NETWORK 100 (1005X4)
(DA3300ES: US, CND/DG1100)
