26
STR-DA3300ES/DG1100
Items Display Remark
Protector on/off PROTECTOR ON/OFF [XXX] XXX: ON or OFF
Model/destination change MODEL [##### * * * *] X X #####: Model, ****: Destination, XX: At or fx
Audio swap SWAP [XXXXXXXXXXX] Switching with M m button of the remote commander
Volume value display (FL/FR) FL**** FR XXXX ****: Front L-ch volume value, XXXX: Front R-ch volume value
Volume value display (SL/SR) SL**** SR XXXX ****: Surround L-ch volume value, XXXX: Surround R-ch volume value
Volume value display (CT/SW) CT**** SW XXXX ****: Center volume value, XXXX: Sub woofer volume value
Volume value display (SBL/SBR) SBL**** SBR XXXX ****: Surround back L-ch volume value, XXXX: Surround back R-ch
volume value
DAC mute information disclosure 1 DAC MUTE U XXXXXXXX Display of module information to demand muting in system controller (for
design evaluation)
DAC mute information disclosure 2 DAC MUTE L XXXXXXXX Display of module information to demand muting in system controller (for
design evaluation)
2nd volume value display 2nd VOLUME XXX XXX: 2nd room volume value (00 to ∞)
FL display duty change DARK OUT DUTY [XXX%] XXX: Duty value of FL display (0% to 100%)
DMPORT debug DMP KEY DEBUG [XXX] XXX: ON or OFF (for debug)
Bus overflow debug HA link OVERFLOW HAL R [XX] XX: Counter of overflow receive buffer
(receive)
Bus overflow debug HA link OVERFLOW HAL S [XX] XX: Counter of overflow transmit buffer
(transmit)
Bus overflow debug DMPORT OVERFLOW CLA [XX] XX: Counter of overflow CLA transmit buffer
