Installation
Installation 13 (GB)
Unit:mm (inches)
60 70 80 90 100 120 150 180 200
A (Vsize) 747 872 996 1121 1245 1494 1868 2241 2490
(29
1
/2) (34
3
/8) (39
1
/4) (44
1
/4) (49
1
/8) (58
7
/8) (73
5
/8) (88
1
/4) (98
1
/8)
B (Hcent) 861 935 1008 1082 1155 1303 1527 1751 1900
(34) (36
7
/8) (39
3
/4) (42
5
/8) (45
1
/2) (51
3
/8) (60
1
/8) (69) (74
7
/8)
D (TD) 2109 2421 2734 3047 3358 3988 4942 5897 6532
(83
1
/8) (95
3
/8) (107
3
/4) (120) (132
1
/4) (157) (194
5
/8) (232
1
/4) (257
1
/4)
E (Xlens) 2050 2354 2659 2962 3265 3877 4804 5733 6350
(80
3
/4) (92
3
/4) (104
3
/4) (116
5
/8) (128
5
/8) (152
5
/8) (189
1
/4) (225
3
/4) (250)
F’ (Lhole) 2314 2618 2923 3226 3529 4141 5068 5997 6614
(91
1
/8) (103
1
/8) (115
1
/8) (127
1
/8) (139) (163
1
/8) (199
5
/8) (236
1
/8) (260
1
/2)
G (Lmax) 2683 2987 3292 3595 3898 4510 5437 6366 6983
(105
3
/4) (117
5
/8) (129
5
/8) (141
5
/8) (153
1
/2) (177
5
/8) (214
1
/8) (250
3
/4) (275)
H (Lfront) 2012 2316 2621 2924 3227 3839 4766 5695 6312
(79
1
/4) (91
1
/4) (103
1
/4) (115
1
/8) (127
1
/8) (151
1
/4) (187
3
/4) (224
1
/4) (248
1
/2)
Screen size
(inches)
Screen with 16:9 aspect ratio
