Sony VPH-D50HTU - Page 16

Installation
16 (GB) Installation
Unit:mm (inches)
60 70 80 90 100 120 150 180 200
A (Vsize) 747 872 996 1121 1245 1494 1868 2241 2490
(29
1
/2) (34
3
/8) (39
1
/4) (44
1
/4) (49
1
/8) (58
7
/8) (73
5
/8) (88
1
/4) (98
1
/8)
B (Hcent) 135 124 113 102 91 69 35 1 –21
(5
3
/8) (5) (4
1
/2) (4
1
/8) (3
5
/8) (2
3
/4) (1
7
/16)(
1
/16)(–
27
/32)
E (Xlens) 2132 2447 2764 3079 3394 4030 4994 5960 6601
(84) (96
3
/8) (108
7
/8) (121
1
/4) (133
5
/8) (158
3
/4) (196
3
/4) (234
3
/4) (260)
F (Lhole) 2327 2642 2959 3274 3589 4225 5189 6155 6796
(91
5
/8) (104
1
/8) (116
1
/2) (129) (141
3
/8) (166
3
/8) (204
3
/8) (242
3
/8) (267
5
/8)
G (Lmax) 2810 3125 3442 3757 4072 4708 5672 6638 7279
(110
5
/8) (123
1
/8) (135
5
/8) (148) (160
3
/8) (185
3
/8) (223
3
/8) (261
3
/8) (186
5
/8)
Screen size
(inches)
Screen with 16:9 aspect ratio
Installation Diagrams
