16 User manual 208898
3. Taking an Exposure CRANEX Novus e
For edentulous patients use the lip holder and
insert it into the round hole at the rear of the chin
rest.
3. Place the appropriate disposable covers on to
the patient support you are using.
4. Press the appropriate panoramic program key
to select the Adult or Child child program. The
key color will change, which indicates that the
program has been selected.
To select the Sectional Panoramic program,
fi rst select Adult program and then Sectional
Panoramic program.
The magnifi cation for the exposures is 1.25.
Adult Child
Sectional Pan.
Approved: Ukkonen Juha-Pekka 2015-03-13 13:08
Reviewed: Savinen Antti Juhani 2015-03-12 11:32
Approved
See PDM system to determine the status of this document. Printed out: 2016-01-27 12:19:26
D508980, 4
Copyright © 2015 by PaloDEx Group Oy. All rights reserved.
