25/08/2004 ©
Söring
Service-Manual Arco- and RF-units
1
not valid for A-3000/ -2000
2
not valid for Arco-2000
-73-
3
not valid for MBC600
4
not valid for Arco-1000
7.4 Limits: min. 9 max. 13
Bit 2, power supply voltage outside of limits; power supply defective
7.5 Limits: min. 20 max. 24
Bit 3, power supply voltage outside of limits; power supply defective
7.6 Limits: min. 43 max. 49
Bit 4, power supply voltage outside of limits; power supply defective
7.7 Limits: min. 86 max. 99
Bit 5, power supply voltage outside of limits; power supply defective
7.8 Limits: min. 170 max. 195
Trigger power supply watchdog, maximum value 100V; power supply defective
7.9 Limits: min. 0 max. 1
Trigger power supply watchdog, back to 0V
8. Test of handpiece recognition function
8.1 Limit: 10
Test channel 1: result must be 0; HSE defective
8.2 Limit: 10
Test channel 2: result must be 10; HSE defective
9. Resonance frequency serial resonant circuit RF-out, test of PE-channel
9.1 Limits: min. 80 max. 200
Search for frequency minimum, gives information about patient safety capacitor
9.2 Limits: min. 0 max. 32
Test PE-recognition; PE-recognition defective
9.3 Limits: min. 176 max. 255
Test PE-recognition; PE-recognition defective
9.4 Limits: min. 176 max. 255
Test PE-recognition; PE-recognition defective
10. Test of output relays
10.1 min 1. 0 / min 2. 176 max 1. 48 / max 2. 255
Relay test #3: switching changes; Relay #3 defective
10.2 min 1. 176 / min 2. 0 max 1. 255 / max 2. 48
Relay test #5: switching changes; Relay #5 defective
10.3 min 1. 176 / min 2. 0 max 1. 255 / max 2. 48
Relay test #6: switching changes; Relay #6 defective
10.4 min 1. 176 / min 2. 0 max 1. 255 / max 2. 48
Relay test #7: switching changes; Relay #7 defective
10.5 min 1. 176 / min 2. 0 max 1. 255 / max 2. 48
Relay test #8: switching changes; Relay #8 defective
10.6 min 1. 0 / min 2. 145 max 1. 10 / max 2. 172
Relay test #4: switching changes; Relay #4 defective
11. Determination of offset values in measurement channels with high precision
Repetition of offset determination
11.1 Limits: min. 0 max. 5 Measuring channel I80 defective
determine offset of I80
11.2 Limits: min. 0 max. 5 Measuring channel U80 defective
determine offset of U80 (Output voltage high power supply)
11.3 Limits: min. 1 max. 16 Measuring channel PWR defective
determine offset of PWR (RF-output voltage CPU-ADC)
11.4 Limits: min. 1 max. 83 Measuring channel PWR_L defective
determine offset of PWR_L (RF-output power Low I
2
C-ADC)
11.5 Limits: min. 6 max. 57 Measuring channel PWR_H defective
determine offset of PWR_H (RF-output power High I
2
C-ADC)
11.6
Limits: min. 0 max. 9 Measuring channel HF_VOLT defective
determine offset of HF_VOLT (RF-output voltage)
