User Manual
4.0: TOUCH SCREEN
TOUCH SCREEN
4.0: TOUCH SCREEN
The console colour Touch Screen can be used through direct touch, or in conjunction with the
Scroll Encoder and the MENU / APPLY buttons. It provides access to System settings and
preferences, Copy/Paste and cuelist / Show functionality, as well as settings for inputs, outputs
monitoring, the solo system, plus a frequency response-type display of the 4-band EQ.
MENU
Access the Touch Screen Main Menu.
Encoder
Scroll or adjust parameters, and select value elds.
Turn the Encoder to navigate a menu; press the Encoder to select a value field for adjustment, then turn the
encoder again to adjust the value field.
APPLY
Apply the set value, where applicable.
The Apply button will illuminate white when required to confirm values.
