6.3.1: MATRIX OUTPUTS SETUP
CHANNELS & BUSSES > MATRIX OUTS > SETUP
6.3.1: CHANNELS & BUSSES > MATRIX OUTPUTS > SETUP
Name
Name the selected Matrix Bus.
When the Name field is selected, a QWERTY keyboard will appear on the Touch Screen so you can enter the desired
name.
Isolate
Isolate the Matrix Master DSP Channel from automation playback.
When a new cue is loaded, this channel will not be aected and its setting will not be changed. However, current
channel settings are still stored when a cue is stored.
Matrix Width
Choose Mono or Stereo type for the Matrix Master Output.
Patching
Choose specic analogue or digital outputs for the Master Output Channel.
Touching the value fields will bring up the standard Patching setup on the Touch Screen. Two outputs can be
allocated, with individually patchable left and right connections. For more detail, please see section 5 - Inputs &
Outputs.
There are various Matrix output-specic options, found via the Touch Screen Main Menu OUTPUTS button.
These offer naming, isolate, width, and physical output patching.

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
