SoundCraft Si EXPRESSION User Manual

User Manual
6.4.1: MAIN MIX OUTPUTS SETUP
CHANNELS & BUSSES > MAIN MIX OUTS > SETUP
6.4.1: CHANNELS & BUSSES > MAIN MIX OUTPUTS > SETUP
Name
Name the selected Main Output Bus.
When the Name field is selected, a QWERTY keyboard will appear on the Touch Screen so you can enter the desired
name.
Isolate
Isolate the Main Output Master DSP channel from automation playback.
When a new cue is loaded, this DSP channel will not be aected and its setting will not be changed. However, current
channel settings are still stored when a cue is stored.
Patching
Choose specic analogue and digital outputs for this DSP Channel.
Touching the value fields will bring up the standard Patching setup on the Touch Screen. Two outputs can be allocat-
ed for both the L&R and the M channels. For more detail, please see section 5 - Inputs & Outputs.
There are various Main Left/RIght and Mono-specic options, found via the Touch Screen Main Menu
OUTPUTS button. These offer naming, isolate, and physical output patching.

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
