SoundCraft Si EXPRESSION User Manual

User Manual
6.1.1: INPUT SETUP
CHANNELS & BUSSES > INPUT CHANNELS > SETUP
6.1.1: CHANNELS & BUSSES > INPUT CHANNELS > INPUT SETUP
Name
Name the selected input channel.
When the Name field is selected, a QWERTY keyboard will appear on the Touch Screen so you can enter the desired
name.
Isolate
Isolate this channel from automation playback.
When a new cue is loaded, this channel will not be aected and its setting will not be changed. However, current
channel settings are still stored when a cue is stored.
Please note: To prevent conflict, Isolation function does not include 48V and pre-amp gain.
Type
An input channel can either be Mono, Linked, or Stereo.
Stereo channels on this console are fixed as ST1 - ST6 and therefore the Type parameter is not editable. Mono Chan-
nels can be linked in consecutive Odd/Even pairs. Linked mono channels act in unison though the 48V and phase
buttons, and the Delay, Gain, and Pan controls remain independent.
There are various input-specic options, found via the Touch Screen Main Menu INPUTS button. These offer
channel naming, linking, Pre/Post routing options for Mix Busses and Direct Outputs, and physical input and
Direct Output patching.

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
