User Manual
6.1.1: INPUT SETUP
CHANNELS & BUSSES > INPUT CHANNELS > SETUP
6.1.1: CHANNELS & BUSSES > INPUT CHANNELS > INPUT SETUP
MIX 1-14 Pre/Post
Set individual Pre- or Post-Fade routing to Mix Busses 1-14.
There are two options for Pre-Fader routing. This is selected in the Output Bus setup menu.
DirectOut Pre/Post
Choose whether the Direct Output patch is sourced Pre Filter or Post Filter.
Post Filter is immediately after the HPF (High Pass Filter) but before the main EQ and Dynamics processing stages.
Pre Filter is immediately after the Analogue To Digital conversion, before the Trim, Phase, and Delay stages.
DirectOut Patch
Choose a physical output for this channel's Direct Output.
Touching the value field will bring up the standard Patching setup on the Touch Screen. For more detail, please see
section 5 - Inputs & Outputs.
Input Patch
Choose a physical input for this input channel.
Touching the value field will bring up the standard Patching setup on the Touch Screen. For more detail, please see
section 5 - Inputs & Outputs.
Set Global Post/Pre
Set a global Pre- or Post-Fader routing for all Mix bus contributions from the input channel.
Alternatively, the Pre- or Post-fader routing can be set individually for the each Mix Bus contribution. This setting can
be overridden by the Output Bus setup. Also, there are two options for Pre-Fader routing, which are selected in the
Output Bus setup menu.
