SoundCraft Si EXPRESSION User Manual

User Manual
6.2.1: MIX OUTPUTS SETUP
CHANNELS & BUSSES > MIX OUTPUTS > SETUP
6.2.1: CHANNELS & BUSSES > MIX OUTPUTS > OUTPUTS SETUP
Name
Name the selected Mix Bus.
When the Name field is selected, a QWERTY keyboard will appear on the Touch Screen so you can enter the desired
name.
Isolate
Isolate the Mix Bus Master DSP Channel from automation playback.
When a new cue is loaded, this DSP Channel will not be aected and its settings will not be changed. However,
current channel settings are still stored when a cue is stored.
Mix Width
Select Mono or Stereo width for this Mix Bus.
Note, only Mix busses 7-14 can be switched to stereo. Mix busses 1-8 are mono only.
There are various Mix Output-specic options, found via the Touch Screen Main Menu OUTPUTS & DMX
button (when an Output Channel is selected). These offer channel naming, isolate, Pre/Post routing options,
width (stereo/mono) and physical output patching.

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
