5.2: DEFAULT PATCHING
INPUTS AND OUTPUTS > DEFAULT PATCHING
5.2: INPUTS & OUTPUTS > DEFAULT PATCHING
The default patching for Expression consoles - also shows default Fader Layers in brackets.
The console patching can be reset to default via the SYSTEM menu.
Inputs
Expression 1
• Mic In 1-14 > Input Channels 1-14 (Fader Layer A, slots 1-14).
• Mic In 15-16 > Input Channels 15-16 (Fader Layer B, slots 1-2).
• Unassigned inputs x 6 > Input Channels 17-22 (Fader Layer B, slots 3-8).
• Line Inputs 1-4 > Stereo Inputs 1-2 (Fader Layer B, slots 9-10).
• Stereo FX Returns 1-4 > Stereo Inputs 3-6 (Fader Layer B, slots 11-14)
Expression 2
• Mic In 1-22 > Channels 1-22 (Fader Layer A, slots 1-22).
• Mic In 23-24 > Channels 23-24 (Fader Layer B, slots 1-2).
• Unassigned inputs x 14 > Channels 25-38 (Fader Layer B, slots 3-16).
• Line Inputs 1-4 > Channels Stereo Input Channels 1-2 (Fader Layer B, slots 17-18).
• Stereo FX Returns 1-4 > Stereo Input Channels 3-6 (Fader Layer B, slots 19-22).
Expression 3
• Mic In 1-30 > Channels 1-30 (Fader Layer A slots 1-30)
• Mic In 31-32 > Channels 31-32 (Fader Layer B slots 1-2)
• Unassigned inputs x 22 > Channels 33-54 (Fader Layer B slots 3-24)
• Line Inputs 1-4 > Stereo Input Channels 1-2 (Fader Layer B slots 25-26).
• Stereo FX Returns 1-4 > Channels Stereo Input Channels 3-6 (Fader Layer B slots 27-30.
Outputs
• MIXES 1-14 > Analogue Line Out 1-14 (Fader Layer C slots 1-14)
• MTX 1-4 > Not Assigned (Fader Layer D slots 1-4).
• Main L&R > Analogue Line Out 15-16 (Master L&R Fader).
• MONO > Not Assigned (MONO/SEL Fader).

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
