7.2.4: ACS EQUALISER SECTION
DSP ELEMENTS > ACS > EQUALISER
7.2.4: DSP ELEMENTS > ACS > EQUALISER
The channel EQ (Equaliser) section is used
for sculpting the tonal (frequency-based)
balance of the signal. The expression EQ is
a four-band type with two (Hi and Lo)
Shelving lters, and two (Hi Mid and Lo Mid)
fully parametric ‘bell’ lters.
HF Level
Adjust the boost/attenuation of the HF shelving lter.
HF FREQ
Adjust the centre frequency of the HF shelving lter.
The filter will boost or cut the signal at this frequency by the amount set by HF Level. The cut-o frequency will
be lower, according to the filter slope.

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
