User Manual
6.2.1: MIX OUTPUTS SETUP
CHANNELS & BUSSES > MIX OUTPUTS > SETUP
6.2.1: CHANNELS & BUSSES > MIX OUTPUTS > OUTPUTS SETUP
Set Mix Sends Pre/Post
Set all contributions to the Mix Bus Pre- or Post-Fade.
This setting can override settings made in the Input Channel Setup.
Output Patching
Choose specic analogue or digital outputs for this DSP Channel.
Touching the value fields will bring up the standard Patching setup on the Touch Screen. Two outputs can be
allocated, with individually patchable left and right connections. For more detail, please see section 5 - Inputs &
Outputs.
Pre Fader Source
Select which Pre-Fader tap/source is used to supply this Mix Bus.
Only relevant when a Pre-Fade routing is selected in the Input or Output Bus Setup menus. The choices (since
console software version 1.6 either Pre Dynamics or Post EQ (but still pre-mute).
To Next Page
