User Manual
6.4: MAIN MIX OUT
CHANNELS & BUSSES > MAIN MIX OUTPUTS
6.4: CHANNELS & BUSSES > MAIN MIX OUTPUTS
The Main Left, Right, and Mono/Centre (L/R & M/C) busses and master channels are used for the
main mix output and receive their inputs from the Input Channels and Mix Bus Master channels.
The Left and Right busses feed the main Left/Right Master - a Stereo Output DSP Channel - which is permanently
assigned to the Left/Right Control Channel. The Mono bus feeds the main Mono output channel, which during normal
operation is controlled by the MONO/SEL control channel, though that channel is assigned to bus masters in FADER
FOLLOW mode.
The Left/Right and Mono channels include a Graphic Equaliser, though do not use the ACS mic/line input controls
(48V, Gain/Trim, Phase), and they do not have a Gate processing element.
There are various Main Left/Right and M-specic options, found via the T
ouch Screen Main Menu OUTPUTS button.
These of
fer naming, isolate, and physical output patching.
