SoundCraft Si EXPRESSION User Manual

User Manual
7.2: ACS ELEMENTS
DSP ELEMENTS > ACS ELEMENTS
7.5: DSP ELEMENTS > ACS ELEMENTS
The Assignable Channel Strip (ACS) follows the currently selected DSP Channel and provides al-
most all of the controls relating to that. It is broken down in to small colour coded sections making it
easy to identify control groups and functions at a glance.
There is a dedicated control for each function and each control has a dedicated label and scale, just as you would nd
on an analogue mixer
The exact value of any control will be shown on the Touch Screen using the Function Focus feature (see section 7.1)
as you adjust them.

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
