User Manual
7.3: CONTROL CHANNEL
DSP ELEMENTS > CONTROL CHANNEL
7.3: DSP ELEMENTS > CONTROL CHANNEL
SOLO
Press to Solo this DSP Channel (Input Channel, Mix Bus Master, Matrix Master).
See section 8.4 for more information of the console’s Solo system.
FADER
Adjust signal level.
Audio channel / Mix Master: Master level.
FOLLOW MODE (tOTEM button selected): Send level form channel to selected bus.
GEQ Mode (GEQ HI or GEQ LO FADERS button selected): GEQ band gain.
The console uses motorised faders to recall position when switching Fader Layers and so on.
If a Control Channel is unassigned, the fader will resist movement.
