User Manual
8.5: MONITORING
MIX FEATURES > MONITORING
8.5: MIX FEATURES > MONITORING
Delay Time (samples, milliseconds)
Set the Monitor Output delay time.
At 96 Samples (48kHz sampling rate), the parameter unit changes to milliseconds (ms)
Monitor L&R Out Patch
Set the physical patching for the monitor output signal.
The Monitor Output patch is additional to the headphones output.
L&R Monitor Speaker
Enable / disable the Monitor Output patch.
Patching for the monitor output is specified in the separate Monitor L&R OutPatch menu item below.
Mono Check
Outputs a mono sum of the stereo monitor signal.
This adds left and right monitor outputs together. A mono check is important when compatibility with mono play-
back devices is required - some delays and stereo processing can cause mono issues that will not necessarily be
obvious when listening in stereo.
Delay
Enable / disable the monitor output delay.
The monitor output delay can be used to synchronise the monitor output with, for example, the Front Of House out-
put, which can be subject to system and distance delays, making monitoring in the same environment dicult.
Monitoring Settings Menu
You access the Monitor Settings menu by touching the
MONITOR Touch Screen button from the Main Menu.
