User Manual
SHOWS, CUELIST, SNAPSHOTS > SHOWS
9.1: SHOWS, CUELIST, SNAPSHOTS > SHOWS
LOAD
Initiate the Load Show process.
You can navigate the internal file system (MMC) or USB key (if present) and select a Show File to load by pressing
the APPLY button. The system will provide a warning that the action will overwrite the current show and allows
the action to be aborted.
SAVE AS
Initiate the process of saving the current show.
When you press SAVE, the QWERTY keyboard is shown with the current show name. You can continue the save
action with the current name (and overwrite) or change the name to create a new show file. Press APPLY to
confirm the name and navigate the file system to confirm the save location.
RESET CONFIG
Re-establish the system conguration.
Clears the console database of any option cards or external I/O systems that may have been attached to the
console then forces a ‘re-discovery’ of any installed option cards or connected I/O system, such as a Soundcraft
Stagebox. The system will provide a warning that the action will overwrite the current configuration database and
allow the action to be aborted.
Show Name
Edit the name of the current Show..
Touching the value field will bring up a QWERTY keyboard screen where you can edit the Show Name.
Global Isolate Filters
Select and Isolate parameters from recall by the automation system.
If a parameter or group of parameters are set to 'Isolate', they will not be changed from the current setting when
a new snapshot is recalled, even if the snapshot has a dierent setting. Isolate settings for individual channels are
available via the INPUTS and OUTPUTS menus. NOTE: All parameters are saved with a snapshot, regardless of the
any Isolate settings.
9.1: SHOWS
