Router Configuration Screen Descriptions
RAC2V1A Router User Guide 48
Wireless Mode Select the proper mode to support all of the
wireless devices that will connect to the router.
2.4 GHz options are:
• 802.11n
• 802.11g+n
5 GHz options are:
• 802.11n
• 802.11n&802.11ac
• 802.11ac
The theoretical bandwidth for 802.11g is up to
54 Mbps. The theoretical bandwidth for 802.11n is
up to 600 Mbps. The theoretical bandwidth for
802.11ac is up to 1.3 Gbps.
Channel
Bandwidth
Sets the 802.11n Channel Bandwidth. Options are:
• 20 MHz
• 20/40 MHz
• 40 MHz
• 20/40/80 MHz (5 GHz only)
The default bandwidth for 2.4 GHz is 20/40 MHz,
and the default bandwidth for 5 GHz is
20/40/80 MHz.
Broadcast
Network Name
(SSID)
Click this checkbox to allow the router to broadcast
the network name (SSID). If you enable this, the
Wi-Fi network name (SSID) will be visible to all
users in the area, including both authorized and
unauthorized users. If you would like others not to
see the access point, uncheck the checkbox to hide
the Wi-Fi network name (SSID).
AP Isolation Click this checkbox to enable AP isolation. When
enabled each of the wireless clients will be in its
own virtual network and will not be able to
communicate with one another. This may be useful
if you have many guests using the network.
Enable WMM Click this checkbox to enable Wi-Fi Multimedia
(WMM) functionality. Enabling WMM can help
