Spectrum RAC2V1A User Manual

Router Configuration Screen Descriptions
RAC2V1A Router User Guide 61
Port Forwarding Table
Enable Clear this checkbox if you want to stop forwarding
this port but do not want to remove it from the
table.
Description
Enter a name for the port you want to forward.
WAN Choose whether the port forward should be
directed to a client on the default LAN (192.168.1.x)
or on a Routing Information Protocol (RIP) gateway.
Inbound Port Enter the inbound port range for the port you want
to forward. It should be the same range as the local
port.
Type Set the format for the port. Options are TCP, UDP,
or BOTH.
Private IP
Address
Enter the IP address of the machine on the LAN
where you want the connections to go.
Private Port Enter the private port range for port you want to
forward. It should be the same range as the inbound
port.
Port Triggers

Spectrum RAC2V1A Specifications

General

Brand	Spectrum
Model	RAC2V1A
Category	Network Router
Language	English
