Installation and Reference Manual
Platform Overview
Installation and Reference Manual v3.2/0410/6 5
This module provides connection for standard analogue telephones:
• Available as 4315 providing 15 POTS ports or 4330
providing 30 POTS ports
• Support for DTMF analogue handsets, PCS 5/10, fax
machines and modems
• Caller Display support
• On-hook voltage 48V, off-hook current 25 mA, ring
voltage 44V rms
• 10/100 LAN port for connection to network
• PCMCIA slot for wireless LAN connection
• Provided with PCS 60 or PCS 50 application to partner an analogue handset from a Windows or Mac
OSX PC
The 4140 Remote Call Server is designed either for the smaller business or the small remote office as part
of a larger network.
• PBX
• 2 x BRI (4 channels) / NT ports
• Optional additional 2 x BRI (4 channels)/NT ports
• Optional PRI (15 channels) / NT / DPNSS port
• 8 x POTS ports
• IP Router
• 1 port QoS 10/100 Base-T switch
• IP WAN port V.11 - megastream 2 Mb (for connection to a Call Server only)
• H.323 Gatekeeper
• H.323 Gateway
• Hard disk storage for software (10 GB), LDAP database, voicemail, Internal Web Server and feature
licenses
• 48 volts PSU (so can purchase commercial UPS)
• Supports H.450.2 (Call Transfer), H.450.4 (Hold), H.450.5 (Park) and H.450.7 (Message Waiting)
• SIP Proxy Server support
• Supports SIP and H.323 trunk services
• Supports NAT Traversal
• Native mode – G.711 64K with echo cancellation
• Optional Compression card supporting G.729 8K for WAN links
• Supports 40 Users (8 analogue plus a further 32 analogue and/or IP)
