Installation and Reference Manual
Technical Data
328 Installation and Re
ference Manual v3.2/0410/6
LAN ports (front) 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN ports.
These ports may also provide power over LAN to IEEE 802.3af compliant
attached devices.
10/100BaseT Full Duplex, MDI LAN port. (Call Server only)
Basic rate ISDN ports meeting CTR3 – see safety statement.
Primary rate ISDN port meeting CTR4 – see safety statement.
WAN port V.11 (X.21) WAN interface operating up to 2.048Mb/s.
Event inputs Opto-coupled inputs to trigger events – see text for details.
Opto-coupled outputs to control external devices – see text for details.
DC Power Inlet 2.5mm jack socket for 48V, 1A power supply.
PCMCIA
Support for 5V and dual voltage 5V/3.3V cards. Support is also dependent on
10/100BaseT Full Duplex, MDI LAN port.
POTS ports Telephone ports – see safety statement concerning TNV-2.
Off hook voltage = 48V
Ringing Voltage = 44Vrms
2.5mm jack socket for 48V, 1A power supply.
10/100BaseT Full Duplex, MDI LAN port.
Basic rate ISDN ports meeting CTR3 – see safety statement.
PRI port Primary rate ISDN port meeting CTR4 – see safety statement.
WAN port V.11 (X.21) WAN interface operating up to 2.048Mb/s.
Event inputs Opto-coupled inputs to trigger events – see text for details.
Opto-coupled outputs to control external devices – see text for details.
POTS ports Telephone ports – see safety statement concerning TNV-2.
Off hook voltage = 48V
Ringing Voltage = 44Vrms
4400 Voice Compression Module
DC Power Inlet 2.5mm jack socket for 48V, 1A power supply.
LAN port 10/100BaseT Full Duplex, MDI LAN port.
Cable Specifications
Warning:
The products are not designed to directly connect to cables that are routed external to a
building.
The RJ45 ports on the units (i.e. ISDN ports and LAN ports) are connected to other devices using standard
category 5 UTP patch cables. These may be supplied with the units but are also commercially available
from numerous retail outlets.
