Splicecom Maximiser - PCS 100 Technical Details

Installation and Reference Manual
Technical Data
336 Installation and Re
ference Manual v3.2/0410/6
Port definitions
PCMCIA Support for 5V and dual voltage 5V/3.3V cards. Support is also dependent on
available s/w drivers.
USB Host Interface USB 1.1
DC Power Inlet
2.5mm jack socket for optional 48V power supply.
PC port
10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port.
LAN port 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port and 802.3af compliant power
sink
Headset port
General 4 pin headset connection. Inner pins connect to earpiece and outer pins
connect to microphone.
Handset port
For connection of supplied handset.
Power Supply Considerations
The product may be powered from either the LAN port or the DC Power Inlet. The DC Power Inlet will
take precedence if both are supplied.
An 802.3af compliant power supply can provide up to 12.95W to the LAN port. Care should be exercised
when adding USB or PCMCIA devices as exceeding the available power will cause the PCS400 to shut
down. The nominal power requirement for the PCS400 alone is 11W. Sufficient power is generally
available to drive a USB keyboard and mouse. If greater power is required then the DC Power Inlet
should be used (or alternatively an externally powered USB hub).
The DC Power Inlet may be connected to a 48Vdc power source. (Available from your re-seller.) This will
provide sufficient power for any USB or PCMCIA compliant devices.
PCS 100 Technical Details
Approval
The product is CE compliant according to the European Directives for Safety and EMC.
Safety Caution
The product should not be disassembled. There are no user serviceable parts.
General
Dimensions (mm) 275(w) x 190(d) x 145(h)
Weight (Kg)
1.1
Environmental
0 to 40°C
85% Relative Humidity, non condensing
LCD
Resolution 64 x 128
Monochrome shades 2
