Splicecom Maximiser - PCS 570;560 Technical Details

Installation and Reference Manual
Technical Data
Installation and Reference Manual v3.2/0410/6 333
Safety Caution
The product should not be disassembled. There are no user serviceable parts.
General
Dimensions (mm): 277(w) x 136(d) x 208(h)
Weight (Kg): 1.5
Environmental: 0 to 40°C
85% Relative Humidity, non condensing
LCD
Technology: TFT
Resolution: 240x320
Colours: 262144
Port definitions
LAN port: 10/100/1000BaseT Full Duplex, Auto MDI/MDI-X LAN port and 802.3af compliant power sink
PC port: 10/100/1000BaseT Full Duplex, Auto MDI/MDI-X LAN port.
Handset port: For connection of supplied handset.
Headset port: General 4 pin headset connection. Inner pins connect to earpiece and outer pins connect
to microphone.
USB Host Interface: USB 2.0 supporting Hi-Speed (480Mb/s), Full-Speed (12Mb/s) and Low-Speed
(1.5Mb/s). Support of devices also depends on driver availability.
Power Supply Considerations
The product is powered from the LAN port.
The PCS570G is a class 2 802.3af compliant powered device, i.e. draws less than 7W from the 802.3af
power source.
PCS 570/560 Technical Details
Approval
The product is CE compliant according to the European Directives for Safety and EMC.
Safety Caution
The product should not be disassembled. There are no user serviceable parts.
General
Dimensions (mm): 277(w) x 136(d) x 208(h)
Weight (Kg): 1.5
Environmental: 0 to 40°C
85% Relative Humidity, non condensing
