Splicecom Maximiser - PCS 400 Technical Details

Installation and Reference Manual
Technical Data
Installation and Reference Manual v3.2/0410/6 335
LCD
Resolution
640 x 480
Colours 262144
Port definitions
USB Host Interface USB 2 (High/Full and Low speeds)
PC port
10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port.
LAN port 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port and 802.3af compliant power
sink
Headset port General 4 pin headset connection. Inner pins connect to earpiece and outer pins
connect to microphone.
Handset port
For connection of supplied handset.
Power Supply Considerations
The product is powered from the LAN port.
An 802.3af compliant power supply can provide up to 12.95W to the LAN port. Care should be exercised
when adding USB devices as exceeding the available power will cause the PCS410 to shut down.
Sufficient power is generally available to drive a USB keyboard and mouse. If greater power is required
then an externally powered USB hub may be used.
PCS 400 Technical Details
Approval
The product is CE compliant according to the European Directives for Safety and EMC.
Safety Caution
The product should not be disassembled. There are no user serviceable parts.
The internal Cold Cathode Fluorescent Lamps used to back light the LCD operate at high voltage and
could pose a shock risk if exposed.
General
Dimensions (mm)
275(w) x 190(d) x 145(h)
Weight (Kg) 1.73
Environmental 0 to 40°C
85% Relative Humidity, non condensing
LCD
Resolution
640 x 480
Colours
262144
