Splicecom Maximiser - Phones

Installation and Reference Manual
Field Descrptions
316
Installation and Reference Manual v3.2/0410/6
Module Status
Member A module that is a part of the system
Available A module that is waiting for permission to join
NonMember
Non members are modules that are part of another system, but because of the network
are visible for this domain. This mode prevents them joining the wrong domain.
IP Address
IP Address of this module, in xxx.xxx.xxx.xxx form.
Flash LED
The Flash LED button will instruct the VCM’s SpliceCom LED to flash 20 times.
Product Version
Software version running on this module.
Call Server
Name of the Call Server to which the VCM is registered.
Phones
Analogue extension port
POTS Phone page
Name
64 Domain Characters. The name of this port.
Description
128 Characters. Text description for this port.
Location
To provide Location Text Information for SNMP
Product Version
Not applicable
Caller Display Type
None Call Display information will not be sent to the extension and the extension will not
ring once after the relevant Phone Module has been rebooted
Default
PCS 10 (suitable for most analogue handsets)
Alarm For use with alarm systems, DTMF is not sent out but allows the alarm system to send
DTMF tones back out.
Bell USA
BT
UK
BTNoMessages
For use with InterQuartz Discovery analogue phones
DTMF Europe
Fax For use with a fax machine connected to this port, provides a strong/robust ring tone
improving the fax machine’s ability to answer a call
FaxServer
For Fax Server support, please refer to page 182 for further details.
Lamp
For use with a PCS 505 or PCS 5 to support the message waiting lamp
