Installation and Reference Manual
Field Descriptions
Installation and Reference Manual v3.2/0410/6 317
For use with InterQuartz Gemini analogue phones
Pay Phone For use with a pay phone
PCS 10 For use with the PCS 10
For use with a PCS 10 to support the message waiting lamp
System Phone For use with the PCS 520, ensures CLI information is displayed correctly and enables
paging and auto answer functionality
Trunk Sends a disconnect signal to the end device.
The number of characters to be sent to the port. Default = 0 which represents 20 characters.
1-8 digit code. Used to secure ability to run PCS50 as an assistant on this port.
Enable/Disable. Allows the use of headset without the need to lift the receiver
Enable/Disable. If enabled DTMF will be regenerated on this port rather than passed Inband.
Auto / H.245 Signal / RTP Event / Inband only
Default = Auto. Used when equipment such a fax server or alarm system is connected to this port.
Determines how the analogue port will receive DTMF tones from the line. Leave as Auto unless specified
by the third party equipment.
Enable/Disable. This field is used in conjunction with a 5100 Call Server. The first eight analogue ports on
a 5100 Call Server are activated on installation. However ports 9-16 require a POTS licences to enable
each port. This field will be ticked when the phone port is unlicensed. The tick should be removed when
a POTS licence has been purchased.
None For use if this port is to be used as a standard extension with analogue phone.
For use if powered speakers are to be connected to this port for use as a Tannoy.
For use if an external Music-on-Hold source is to be connected to this port.
The number to be dialled by the system when the User assigned to this port is working from home or on
a mobile and wishes to handle calls as though they were in the office.
Seconds. The number of seconds that the User’s home telephone will remain idle before a call from the
imiser system is cleared.
The name of the User to whom this port is assigned.
Fields specific for an IP Phone listed under a Call Server:
