Port Definitions
Call Server 5100
DC Power Inlet 2.5mm jack socket for 48V, 1.35A power supply.
POTS ports (16) Telephone ports – see safety statement concerning TNV-2.
Off hook voltage = 48V
Ringing Voltage = 44Vrms
Loop current = 25mA
LAN ports (4) 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN ports.
These ports may also provide power over LAN to IEEE 802.3af compliant
attached devices.
LAN LINK port
10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port.
BRI ports (4)
Basic rate ISDN ports meeting CTR3 – see safety statement.
PRI ports (2) Primary rate ISDN ports meeting CTR4 – see safety statement.
Event inputs (2) Opto-coupled inputs to trigger events – see text for details.
Relay outputs (2)
Opto-coupled outputs to control external devices – see text for details.
USB Host Interface
USB 2 (High/Full and Low speeds)
Phone 53xx
DC Power Inlet
2.5mm jack socket for 48V, 1.35A power supply.
POTS ports (xx) Telephone ports – see safety statement concerning TNV-2.
Off hook voltage = 48V
Ringing Voltage = 44Vrms
Loop current = 25mA
LAN ports (4) 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN ports.
These ports may also provide power over LAN to IEEE 802.3af compliant
attached devices.
LAN LINK port 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port.
Event inputs (2) Opto-coupled inputs to trigger events – see text for details.
Relay outputs (2) Opto-coupled outputs to control external devices – see text for details.
USB Host Interface
USB 2 (High/Full and Low speeds)
Call Server 5108
DC Power Inlet 2.5mm jack socket for 48V, 1.35A power supply.
POTS ports (4) Telephone ports – see safety statement concerning TNV-2.
Off hook voltage = 48V
Ringing Voltage = 44Vrms
Loop current = 25mA
LAN ports (4) 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN ports.
These ports may also provide power over LAN to IEEE 802.3af compliant
attached devices.
LAN LINK port 10/100BaseT Full Duplex, Auto MDI/MDI-X LAN port.
BRI ports (2) Basic rate ISDN ports meeting CTR3 – see safety statement.
Event input Opto-coupled input to trigger events – see text for details.
Relay output
Opto-coupled output to control external devices – see text for details.
4100 Call Server/4200 Trunk
DC Power Inlet 2.5mm jack socket for 48V, 1A power supply.
DC Power over LAN
5 pin DIN socket for 48V, 2.7A power supply.
