Splicecom Maximiser - Page 317

Installation and Reference Manual
Field Descriptions
Installation and Reference Manual v3.2/0410/6 311
Product Version
Software version running on this module
Module Status
Member
A module that is a part of the system
Available A module that is waiting for permission to join
NonMember
Non members are modules that are part of another system, but because of the
network are visible for this domain. This mode prevents them joining the wrong
domain.
Flash LED
The Flash LED button will instruct the Call Server’s SpliceCom LED to flash 20 times.
Call Server/Remote Call Server page
Administration Mode
Primary A Call Server that is the master administrative module controlling the configuration
database.
Secondary A Call Server that is linked to a Primary Call Server and receives its configuration from the
Primary.
DHCP Server Mode
Enable The Call Server will act as the DHCP server using the IP Address range specified in the DHCP
Start Address and DHCP End Address fields. If another DHCP Server has been detected on
the network and the Call Server is rebooted it will keep its previous IP address and disable its
own DHCP server.
Disable
DHCP is disabled; the Call Server will use the IP address entered in the IP Address field within
the General page.
Client The Call Server will act as the DHCP client obtaining an IP address from a DHCP Server on the
network.
DHCP Start Address
First IP address of the IP address range to be used when the DHCP Server Mode is set to Enable. Default
= 192.168.0.2. (Please note that this field is irrelevant if the DHCP Server Mode is set to Disabled.)
DHCP End Address
Last IP address of the IP address range to be used when the DHCP Server Mode is set to Enable. Default
= 192.168.0.250. The system assumes a linear distance between the two numbers and has no knowledge
of sub address masks. (Please note that this field is irrelevant if the DHCP Server Mode is set to Disabled.)
DHCP Base Address
Default = 192.168.0.0. The network on which the Call Server will allocating IP addresses.
DHCP Base Mask
Default = 255.255.255.0. IP address mask to be used by the Call Server.
DHCP Router
Default Gateway
